Well Pack Solutions

(Click on thumbnail to enlarge)Well Pack

Kleen Industrial Services is single source manufacturer and distributor of filter media to the US and Canada for over 35 years. Our materials uniform grain shapes and grain size distributions produce efficient filtration bed operation for removal of contaminants in both potable water and wastewater.

Clean and chemically inert, our silica products will not degrade or react when it comes in contact with acids, contaminants, volatile organics or solvents due to its low acid solubility.

Due to our materials sub-angular shape and uniform size, they are ideal for use as packing material in deep-water wells to increase yield from the aquifer by expanding the permeable zone around the well screen and preventing the infiltration of fine particles from the formation.

The uniformity and low acid solubility also minimizes material lost during well development. The sub-angular shape aids hydraulic conductivity by reducing drawdown and improving yield. Kleen Industrial Services silica products meet or exceed all AWWA recommendations for filter sand and are NSF Certified.

Municipalities, engineering firms, and well screen manufacturers routinely spec Kleen Industrial Services Sand and Gravel well pack media for its desirable physical and chemical properties.

U.S. Sieve SizesTypical Sieve Analysis
Standard SieveOpening Inches5/98/1210/2020/4040/6040/100
Percent Passing
Typical Physical PropertiesComposite Typicals
pHNeutral (7.0)AluminumAl2O31.07
Roundness.4+Iron OxideFe2O30.11
Sphericity0.7+Sodium OxideNa2O0.13
Hardness7.0Potassium OxideK2O0.16
Specific Gravity2.65Calcium OxideCaO0.02
LOI (Loss on Ignition)<0.4Magnesium OxideMgO0.09
Unit Weight~100lbs. per Cubic FootTitanium DioxideTiO20.03
Acid Solubility< 1.0%Manganese OxideMnO0.04
Porosity44%+Barium OxideBaO0.02
